  Home >> DMR radio >> WOUXUN walkie talkie >> WOUXUN KG-UV8G - 2/4M HANDHELD TRANSCEIVER PRO PACK

WOUXUN KG-UV8G - 2/4M HANDHELD TRANSCEIVER PRO PACK [Comments(0)|Leave your Comment]
Brand:WOUXUN walkie talkie
Item#:12120401414848
Score:0  (Score change Discount Voucher)
Weight:0.85 kg.
List Price:$99.00
Price:$70.00
You Save:$29.00
Qty:

Prev:WOUXUN KG-UV9K PROPACK - HANDHELD DUAL BAND TRANSCEIVER KIT

Next:WOUXUN KG-699E 4M HANDHELD TRANSCEIVER

detail

Related

Comment

Payment

Shipping

WOUXUN KG-UV8G - 2/4M HANDHELD TRANSCEIVER PRO PACK
ABOUT WOUXUN KG-UV8G - 2/4M HANDHELD TRANSCEIVER PRO PACK

Wouxun KG-UV8G 2m And 4m 144/70MHz Handheld Transceiver Pro Pack.

For a Limited Time Offer the factory has put together all your favourite accessories and placed them inside a presentation box.

Features:

  • Dulex Repeater
  • Memory Channels 999
  • QT/DQT Encoding / Decoding , QT / DQT Scan
  • VOX and SOS Funcion
  • Multi Definition for Sidekeys
  • Incoming Message Display Caller ID display
  • DTMF Encoding and Decoding
  • All Calls, Group Calls And Selective Calls
  • Dual Display, Two Independent Operation System
  • Large Color Screen
  • Duplex Work Mode and Dual Receiving
  • Cross Band Repeater
  • Power on Message Editable
  • Wide / Narrow Bandwidth Selection (25KHZ / 12.5KHz)
  • Chinese and English Voice Guide
  • Chinese and English Screen Display
  • Bright Flashlight illumination
  • Reverse Frequency
  • Single-Tone Pulse Frequency: 1000 / 1450 / 1750 / 2100Hz
  • Stopwatch
  • Remote Alarm
  • Priority Scan Function
  • Voice Encryption and Non-Standard CTCSS/DCS
  • Voice Compander

Included in the pack:

  • KG-UVD8G New Dual Band Handie Dual band antenna
  • 20cm long Desktop charger (100-240VAC- 12V input) supplied with UK power supply - no AC power cord supplied
  • Headset with PTT and Mic
  • Battery Eliminator with Cigar Lighter plug
  • Silicon Case
  • Remote Mic/Speaker
  • 2 x 3200mAh Heavy Duty Li-Ion Battery
  • PC Programming Lead, PC Drivers and Software
  • SO239 Adaptor
  • 2 x Battery clip
  • Handle Strap

TECHNICAL SPECIFICATIONS:

Integration

  • Frequency Range: 144-146MHz and 70-70.500MHz
  • Step: 5 / 6.25 / 10 / 12.5 / 25 / 50 / 100KHz
  • Channel Number: 999
  • Work Mode: F2D / F3E
  • Operating Temperature: 20℃~+40℃
  • Voltage: 7.4 VDC
  • Antenna Impedance: 50Ω

Receiver

  • Adjacent Channel Selectivity: WIDE:≤70dB. NARROW: ≤60dB
  • Inter Modulation: WIDE:≤65dB. NARROW: ≤60dB
  • Spurious Response: WIDE:≤70dB. NARROW: ≤70dB
  • Audio Response: WIDE:+1~-3dB(0.3~3KHz). NARROW:+1~-3dB(0.3~3KHz)
  • Signal to Noise Ratio: WIDE:≥45dB. NARROW:≥40dB
  • Audio Distortion: ≤5%
  • Audio Power: 500mW
  • Sensitivity: UHF/VHF:0.25μV(12dB SINAD)

Transmitter

  • Adjacent Channel Selectivity: WIDE: ≥70dB. NARROW: ≥60dB.
  • Type of Modulation: WIDE: 16K F3E. NARROW: 11K F3E.
  • Spurious: WIDE: ≥60dB. NARROW: ≥60dB.
  • Audio Response: WIDE: +1~-3dB(0.3~3KHz). NARROW: +1~-3dB(0.3~3KHz).
  • Max Frequency Deviation: WIDE: ±5KHz. NARROW: ±2.5KHz.
  • Frequency Stability: ±2.5PPM
  • Audio Distortion: ≤5%
  • Output Power: VHF: 10W / 7W / 1W

DELIVERY

We aim to dispatch all parcels within 24hrs. We are normally able to dispatch parcels SAME DAY where orders are received before 2.00pm Monday to Friday.

REVIEWS0

Be the first to review this product
